PSB2103680KHS

Manufacturer :

Nichicon

Product Category :

Film Capacitors

Width :

22 mm

Capacitance :

0.68 μF

Product Type :

Film Capacitors

Voltage Rating - DC :

1000V (1kV)

Operating Temperature :

-40°C ~ 85°C

RoHS :

Details

Height - Seated (Max) :

1.457" (37.00mm)

Length :

32 mm

Product Category :

Film Capacitors

Voltage Rating - AC :

575V

Ratings :

-

Lead Diameter :

1.2 mm

Mounting Type :

Through Hole

Lead Spacing :

1.083" (27.50mm)

Applications :

High Frequency, Switching; High Pulse, DV/DT; Snubber

Package :

Bulk

Subcategory :

Capacitors

Product :

General Film Capacitors

Series :

PSB

Tolerance :

±10%

Dielectric :

Polypropylene (PP)

Manufacturer :

Nichicon

Size / Dimension :

1.260" L x 0.866" W (32.00mm x 22.00mm)

ESR :

3 MOhms

ESR (Equivalent Series Resistance) :

3 MOhms

Package / Case :

Radial

Maximum Operating Temperature :

+ 85 C

Packaging :

Bulk

Features :

-

Termination Style :

Radial

Product Status :

Active

Number of Pins :

4 Pin

Minimum Operating Temperature :

- 40 C

Height :

37 mm

Dielectric Material :

Polypropylene (PP), Metallized

Termination :

PC Pins

Lead Style :

Straight

Brand :

Nichicon
