PWB100A40

Manufacturer :

Sansha Electric

Product Category :

Thyristors - SCRs - Modules

Brand :

SanRex

Type :

Non-Isolated

Number of SCRs, Diodes :

3 SCRs

Manufacturer :

SanRex

Minimum Operating Temperature :

- 30 C

Current - Hold (Ih) (Max) :

70 mA

Package :

Tray

Maximum Operating Temperature :

+ 150 C

Current - Non Rep. Surge 50, 60Hz (Itsm) :

3200A, 3500A

Current - Gate Trigger (Igt) (Max) :

150 mA

Packaging :

Tray

Product Type :

Discrete Semiconductor Modules

Voltage - Off State :

400 V

Series :

PWB

Current - On State (It (AV)) (Max) :

100 A

Structure :

Bridge, 3-Phase - All SCRs

Voltage - Gate Trigger (Vgt) (Max) :

2 V

Product :

Thyristor Power Modules

Current - On State (It (RMS)) (Max) :

157 A

Product Category :

Discrete Semiconductor Modules

Technology :

Si

Subcategory :

Discrete Semiconductor Modules

Product Status :

Active

Operating Temperature :

-30°C ~ 150°C (TJ)

Mounting Style :

Screw Mounts

Tradename :

SanRex

Mounting Type :

Chassis Mount

RoHS :

Details

Package / Case :

Module
