RD15M100EX
Or copy the link below:
- Mfr.Part #
- RD15M100EX
- Manufacturer
- Positronic
- Package / Case
- Datasheet
- Download
- Description
- CONN D-SUB PLUG 15POS CRIMP
- Stock
- 45,673
- In Stock ：
- 45,673
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Positronic
- Product Category :
- D-Sub Connector Assemblies
- Product Status :
- Active
- Base Product Number :
- RD15M
- Dielectric Material :
- Diallyl Phthalate (DAP), Glass Filled
- Mounting Type :
- Free Hanging (In-Line)
- Flange Feature :
- Cable Side, Male Jackscrew (4-40)
- Number of Positions :
- 15
- Ingress Protection :
- IP65/IP67 - Dust Tight, Water Resistant, Waterproof
- Contact Finish Thickness :
- Flash
- Shell Material, Finish :
- Steel, Tin Plated
- Current Rating (Amps) :
- 7.5A
- Package :
- Box
- Shell Size, Connector Layout :
- 2 (DA, A)
- Backset Spacing :
- -
- Contact Material :
- COPPER ALLOY
- Operating Temperature :
- -55°C ~ 125°C
- Contact Type :
- Signal
- Material Flammability Rating :
- UL94 V-0
- Termination :
- Crimp
- Connector Type :
- Plug, Male Pins
- Series :
- RD
- Contact Form :
- Machined
- Number of Rows :
- 2
- Color :
- Green
- Wire Gauge :
- 20-24 AWG
- Voltage Rating :
- 300V
- Connector Style :
- D-Sub
- Contact Finish :
- Gold
- Features :
- -
- Datasheets
- RD15M100EX
RD Series D-Sub Plug, Male Pins 15-Position Signal Crimp 2 (DA, A) Free Hanging (In-Line) Copper Alloy Gold Steel, Tin Plated
RD15M100EX Overview
The connector type Plug, Male Pins refers to the connector type.The device's mounting type is Free Hanging (In-Line).It belongs to the RD Series of products.The device runs in -55°C ~ 125°C Operating Temperature.
RD15M100EX Features
RD series
RD15M100EX Applications
There are a lot of Positronic
RD15M100EX D-Sub Connectors applications.
- Industrial Automation
- Transportation
- Embedded systems
- Datacom
- Communication
- Medical technology
- Military Technology
- Measuring & Control Technology
- Instrumentation
- Automotive Electronics
