SC0914(7)

Manufacturer :

Raspberry Pi

Product Category :

Microcontrollers

Data Bus Width :

32 bit

Package :

Tape and Reel (TR);Cut Tape (CT);Digi-Reel®;

Core Processor :

ARM® Cortex®-M0+

Operating Temperature :

-40°C ~ 85°C (TC)

Maximum Operating Temperature :

+ 85 C

Core Size :

32-Bit Dual-Core

Connectivity :

CANbus, CSIO, EBI/EMI, I²C, LINbus, UART/USART, USB

Supplier Device Package :

56-QFN (7x7)

Packaging :

Cut Tape

Program Memory Size :

-

Number of I/Os :

30 I/O

Base Product Number :

SC0914

Package / Case :

56-VFQFN Exposed Pad

Speed :

133MHz

EEPROM Size :

-

Mounting Style :

SMD/SMT

Peripherals :

Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT

Series :

-

Number of I/O :

30

Product Status :

Active

Oscillator Type :

External, Internal

Product :

MCU

Data Converters :

A/D 4x12b SAR

Mounting Type :

Surface Mount

Voltage - Supply (Vcc/Vdd) :

1.8V ~ 3.3V

Minimum Operating Temperature :

- 40 C

RAM Size :

264K x 8

Program Memory Type :

External Program Memory

Operating Supply Voltage :

1.1 V

Number of ADC Channels :

4 Channel

Interface Type :

I2C, SPI, UART, USB
