SO469420

Manufacturer :

Celduc

Product Category :

Solid State Relays

Depth :

58.2mm

Operating Temperature Range :

-40 → +100°C

Package :

Box

Supplier Device Package :

-

Number of Poles :

1

Series :

SO4

Voltage - Load :

200 V ~ 480 V

Output Type :

AC

Dimensions :

45 x 58.2 x 27mm

Relay Type :

AC

Load Current :

125 A

Range :

SO4

Height :

27mm

Standards Met :

CE Certified, cULus Recognized

Circuit :

SPST-NO (1 Form A)

On-State Resistance (Max) :

2 MOhms

Minimum Operating Temperature :

-40°C

Package / Case :

Module

Product Status :

Active

Mounting Type :

Panel Mount

Length :

45mm

Maximum Operating Temperature :

+100°C

Termination Style :

-

Voltage - Input :

4mA ~ 20mA (Current Loop)

Special Features :

Over-Voltage Protection by Varistor, IP20 Protection by Flaps on Terminals

Terminal Type :

Screw

Output Device :

Thyristor
