STX-3000

Manufacturer :

Kycon

Product Category :

Audio Connectors

Body Depth :

0.551 inch

Contact Resistance :

60mOhm

Contact Style :

RND PIN-SKT

Orientation :

Horizontal

Option :

GENERAL PURPOSE

Industry Recognized Mating Diameter :

3.50mm (0.141, 1/8, Mini Plug) - Headphone

Housing Material :

Polybutylene Terephthalate (PBT)

Voltage - Rated :

250V

Published :

1999

Number of Ports :

1

Length - Termination :

0.11 inch

Durability :

5000 Cycles

IEC Conformance :

No

Mounting Type :

Through Hole, Right Angle

Feature :

Board Guide

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Number of Poles :

3

Connector Type :

Phone Jack

JESD-609 Code :

e3

Reference Standard :

UL, CSA

Mount :

Through Hole

Number of Contacts :

3

Packaging :

Bulk

Gender :

FEMALE

Internal Switch(s) :

Does Not Contain Switch

Termination :

Kinked Pin

Number of Conductors :

ONE

Signal Lines :

Stereo (3 Conductor, TRS)

Reliability :

COMMERCIAL

Withdrawl Force-Min :

2.9468 N

Insulation Resistance :

100000000Ohm

Polarization Key :

POLARIZED HOUSING

RoHS Status :

RoHS Compliant

Actual Diameter :

0.142 (3.60mm)

Factory Lead Time :

20 Weeks

DIN Conformance :

No

Series :

STX-3000

Contact Material :

COPPER ALLOY

Contact Material - Plating :

Tin

Shielding :

Unshielded

Number of Positions/Contacts :

3 Conductors, 3 Contacts

MIL Conformance :

No

Body Color :

Black

Radiation Hardening :

No

Operating Temperature :

-25°C~80°C
