TLP352(TP1,F)

Manufacturer :

Toshiba Electronic Devices and Storage Corporation

Product Category :

Isolators - Gate Drivers

Package / Case :

8-SMD, Gull Wing

Radiation Hardening :

No

RoHS Status :

RoHS Compliant

Turn On Delay Time :

200 ns

Mounting Type :

Surface Mount

Mount :

Surface Mount

Forward Current :

20mA

Number of Pins :

8

Output Current :

2.5A

Approval Agency :

CSA, cUL, UL

Voltage - Isolation :

3750Vrms

Rise Time :

15ns

Factory Lead Time :

12 Weeks

Voltage - Forward (Vf) (Typ) :

1.55V

Pulse Width Distortion (PWD) :

50 ns

Current - Output High, Low :

2A 2A

Number of Channels :

1

Fall Time (Typ) :

8 ns

Published :

2016

Operating Temperature :

-40°C~125°C

Voltage - Output Supply :

15V~30V

Common Mode Transient Immunity (Min) :

20kV/μs

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Max Output Current :

2.5A

Max Power Dissipation :

260mW

Propagation Delay :

200 ns

Propagation Delay tpLH / tpHL (Max) :

200ns, 200ns

Direction :

Unidirectional

Packaging :

Cut Tape (CT)

Rise / Fall Time (Typ) :

15ns 8ns

Reverse Voltage (DC) :

5V

Optoelectronic Device Type :

LOGIC IC OUTPUT OPTOCOUPLER
