TR20FBD2K00

Manufacturer :

Stackpole Electronics, Inc.

Product Category :

Through Hole Resistors

Height :

16.26 mm

Operating Temperature :

-65°C ~ 150°C

Package Width :

3.18

Working Voltage :

350

Lead Length :

12.7

Number of Terminations :

2

JESD-609 Code :

e3

Power Rating :

20 W

Application :

High Power

Height - Seated (Max) :

0.810 (20.58mm)

Minimum Operating Temperature :

- 65 C

Construction :

RECTANGULAR

Failure Rate :

-

Product Status :

Obsolete

Technology :

Thick Film

Voltage Rating :

350 V

Terminal Finish :

Matte Tin (Sn)

Power (Watts) :

20W

Composition :

Thick Film

Package Shape :

RECTANGULAR PACKAGE

Number of Terminals :

2

Product Type :

Thick Film Resistors

Maximum Operating Temperature :

+ 150 C

Package Length :

10.41

Additional Feature :

NON-INDUCTIVE, RATED POWER DISSIPATION USING HEATSINK: 20W

Subcategory :

Resistors

Length :

10.41 mm

Termination Style :

Radial

Size Code :

4112

Package :

Bulk

Size / Dimension :

0.410 L x 0.125 W (10.41mm x 3.18mm)

Rated Temperature :

25

Terminal Shape :

Flat

Package Height :

16.26

Width :

3.18 mm

Supplier Device Package :

TO-220

Temperature Coefficient :

100

Mounting Feature :

THROUGH HOLE MOUNT

Resistance :

2000

Resistor Type :

FIXED RESISTOR

Mounting Style :

PCB Mount

Features :

Moisture Resistant, Non-Inductive

Tolerance :

1

Rated Power Dissipation (P) :

3

Package / Case :

TO-220-2

Lead Spacing :

5.08

Packing Method :

Bulk

Series :

TR
