TR20FBD3K01

Manufacturer :

Stackpole Electronics, Inc.

Product Category :

Through Hole Resistors

RoHS :

Non-Compliant

Mounting Feature :

THROUGH HOLE MOUNT

Number of Terminations :

2

Mounting Style :

PCB Mount

Size / Dimension :

0.410 L x 0.125 W (10.41mm x 3.18mm)

Termination Style :

Radial

Number of Terminals :

2

Supplier Device Package :

TO-220

Packing Method :

Bulk

Package / Case :

TO-220-2

Rated Temperature :

25

Temperature Coefficient :

100

Power Rating :

20 W

Construction :

RECTANGULAR

Subcategory :

Resistors

Minimum Operating Temperature :

- 65 C

Package Length :

10.41

Package Shape :

RECTANGULAR PACKAGE

Maximum Operating Temperature :

+ 150 C

Lead Length :

12.7

Voltage Rating :

350 V

Series :

TR

Product Type :

Thick Film Resistors

Package Height :

16.26

Size Code :

4112

Composition :

Thick Film

Technology :

Thick Film

Package :

Bulk

Terminal Shape :

Flat

Resistance :

3010

Operating Temperature :

-65°C ~ 150°C

Height - Seated (Max) :

0.810 (20.58mm)

Resistor Type :

FIXED RESISTOR

Tolerance :

1 %

Application :

High Power

Width :

3.18 mm

Min Operating Temperature :

-65 °C

JESD-609 Code :

e3

Mount :

Radial, Through Hole

Terminal Finish :

Matte Tin (Sn)

Additional Feature :

NON-INDUCTIVE, RATED POWER DISSIPATION USING HEATSINK: 20W

Lead Spacing :

5.08

Power (Watts) :

20W

Packaging :

Bulk

Failure Rate :

-

Package Width :

3.18

Max Operating Temperature :

150 °C

Product Status :

Obsolete

Rated Power Dissipation (P) :

3

Working Voltage :

350

Length :

10.41 mm

Features :

Moisture Resistant, Non-Inductive

Height :

16.26 mm
