TR35FBC100R

Manufacturer :

Stackpole Electronics, Inc.

Product Category :

Through Hole Resistors

Temperature Coefficient :

±50ppm/°C

Width :

4.6 mm

Operating Temperature :

-65°C ~ 175°C

Failure Rate :

-

Features :

Moisture Resistant, Non-Inductive

Composition :

Thick Film

Length :

10.16 mm

Package Height :

14.75

Termination Style :

Radial

Size / Dimension :

0.400" L x 0.181" W (10.16mm x 4.60mm)

Resistance :

100 Ohms

Rated Power Dissipation (P) :

2.5

Minimum Operating Temperature :

- 65 C

Rated Temperature :

25

Product Type :

Thick Film Resistors

Subcategory :

Resistors

Packing Method :

Bulk

JESD-609 Code :

e3

Height :

15 mm

Lead Free :

Lead Free

Construction :

RECTANGULAR

Additional Feature :

NON-INDUCTIVE, RATED POWER DISSIPATION USING HEATSINK: 35W

Terminal Shape :

Flat

Package :

Bulk

Package Shape :

RECTANGULAR PACKAGE

Power (Watts) :

35W

Working Voltage :

350

Package Width :

4.44

Lead Spacing :

5.08

Series :

TR

Number of Terminations :

2

Size Code :

4017

Lead Length :

13.7

Height - Seated (Max) :

0.762" (19.36mm)

Voltage Rating :

350 V

Tolerance :

±1%

Mounting Feature :

THROUGH HOLE MOUNT

Product Status :

Active

Technology :

Thick Film

Application :

High Power

Power Rating :

35 W

Supplier Device Package :

TO-220

Package / Case :

TO-220-2

Number of Terminals :

2

Resistor Type :

FIXED RESISTOR

Terminal Finish :

Matte Tin (Sn)

RoHS :

Non-Compliant

Package Length :

10.16

Maximum Operating Temperature :

+ 175 C

Mounting Style :

PCB Mount
