UES2606HR2

Manufacturer :

Microchip Technology

Product Category :

Diodes - Rectifiers - Single

Number of Phases :

1

Package Shape :

Round

Qualification Status :

Not Qualified

Number of Elements :

2

Terminal Position :

BOTTOM

Case Connection :

CATHODE

Subcategory :

Rectifier Diodes

Non-rep Pk Forward Current-Max :

300 A

Configuration :

COMMON CATHODE, 2 ELEMENTS

Reverse Recovery Time-Max :

0.05 μs

JEDEC-95 Code :

TO-3

Manufacturer :

Microsemi Corporation

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

JESD-609 Code :

e0

Number of Terminals :

2

Pin Count :

2

Output Current-Max :

30 A

Pbfree Code :

No

Terminal Finish :

Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier

Surface Mount :

No

Application :

EFFICIENCY

Reverse Current-Max :

50 µA

Reach Compliance Code :

Unknown

Rep Pk Reverse Voltage-Max :

400 V

Terminal Form :

PIN/PEG

Additional Feature :

High Reliability

Diode Element Material :

SILICON

HTS Code :

8541.10.00.80

ECCN Code :

EAR99

Diode Type :

RECTIFIER DIODE

JESD-30 Code :

O-MBFM-P2
