UJ4SC075006K4S

Manufacturer :

UnitedSiC

Product Category :

Transistors - FETs, MOSFETs - Single

Series :

-

Operating Temperature :

-55°C ~ 175°C (TJ)

Base Product Number :

UJ4SC075

Power Dissipation (Max) :

714W (Tc)

Packaging :

Tube

Drive Voltage (Max Rds On, Min Rds On) :

12V

Product Status :

Active

Drain to Source Voltage (Vdss) :

750 V

Package / Case :

TO-247-4

Input Capacitance (Ciss) (Max) @ Vds :

8374 pF @ 400 V

Package :

Tube

Manufacturer :

UnitedSiC

Subcategory :

Transistors

Mounting Type :

Through Hole

FET Feature :

-

Mounting Style :

SMD/SMT

Brand :

UnitedSiC

Current - Continuous Drain (Id) @ 25°C :

120A (Tc)

Vgs(th) (Max) @ Id :

6V @ 10mA

Product Category :

JFET

Transistor Polarity :

N-Channel

Maximum Operating Temperature :

+ 175 C

Product Type :

JFETs

RoHS :

Details

Gate Charge (Qg) (Max) @ Vgs :

164 nC @ 15 V

Rds On (Max) @ Id, Vgs :

7.4mOhm @ 80A, 12V

Supplier Device Package :

TO-247-4

Vgs (Max) :

±20V

Minimum Operating Temperature :

- 55 C

FET Type :

N-Channel
