VX-705-EAE-KXAN-125M000000TR

Manufacturer :

Microchip Technology

Product Category :

Oscillators

Current - Supply (Disable) (Max) :

-

Diameter :

2.39 mm

Tolerance :

1 %

Function :

Enable/Disable

Type :

VCXO

Size / Dimension :

0.276 L x 0.197 W (7.00mm x 5.00mm)

Series :

VX-705

Length :

7.62 mm

Operating Temperature :

-40°C ~ 85°C

Height - Seated (Max) :

0.082 (2.09mm)

Output :

CMOS

Base Resonator :

Crystal

Frequency Stability :

±20ppm

Composition :

Metal Film

RoHS :

Compliant

Max Operating Temperature :

175 °C

Military Standard :

MIL-PRF-55182

Package / Case :

6-SMD, No Lead

Temperature Coefficient :

50 ppm/°C

Ratings :

-

Min Operating Temperature :

-65 °C

Package :

Tape and Reel (TR)

Resistance :

4.32 kΩ

Current - Supply (Max) :

25mA

Spread Spectrum Bandwidth :

-

Absolute Pull Range (APR) :

±50ppm

Mounting Type :

Surface Mount

Contact Plating :

Lead, Tin

Mount :

Through Hole

Frequency :

125 MHz

Product Status :

Active

Voltage - Supply :

3.3V
