XUB5BPANM12
Or copy the link below:
- Mfr.Part #
- XUB5BPANM12
- Manufacturer
- Schneider Electric
- Package / Case
- Datasheet
- Download
- Description
- PHOTOELECTRIC SENSORS XU, XUB, D
- Stock
- 20,817
- In Stock ：
- 20,817
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Schneider Electric
- Product Category :
- Optical Sensors - Photoelectric, Industrial
- Ratings :
- IP65
- Max Operating Temperature :
- 55 °C
- Type of electric connection :
- Connector M12
- Cable Length :
- -
- Adjustment Type :
- -
- Explosion safety category for dust :
- NONE
- Width :
- 18 mm
- Housing Material :
- Brass
- Minimum Operating Temperature :
- - 25 C
- Suitable for safety functions :
- yes
- Sensing Method :
- Diffuse
- Max Supply Voltage (DC) :
- 24 V
- Product Status :
- Active
- Rated control supply voltage at DC :
- 12 - 24
- Operating Supply Voltage :
- 24 V
- Connector Type :
- Connector
- Response Time :
- 1ms
- Connection Method :
- Connector, M12
- Voltage - Supply :
- 12V ~ 24V
- Degree of protection (IP) :
- IP67K
- Operating Temperature :
- -25°C ~ 55°C
- REACH SVHC :
- Unknown
- Output Current :
- 100 mA
- Maximum Operating Temperature :
- + 55 C
- Explosion safety category for gas :
- NONE
- Output Configuration :
- PNP-NO
- RoHS :
- Compliant
- Min Supply Voltage (DC) :
- 12 V
- Min Operating Temperature :
- -25 °C
- Max. output current :
- 100
- Number of Pins :
- 4
- Package :
- Box
- Series :
- -
- Material housing :
- Metal
- Sensing Distance :
- 23.622" (600mm)
- Length :
- 76 mm
- Light Source :
- Yellow LED
- Voltage type :
- AC/DC
- Ambient temperature :
- -25 - 55
- Ingress Protection :
- IP65
- Datasheets
- XUB5BPANM12
12V ~ 24V - Series - Diffuse Connector 4-Pin -25°C ~ 55°C
XUB5BPANM12 Overview
A reliable performance can be assured by setting the temperature of the photoelectric sensor to -25°C ~ 55°C. Electronic components require a voltage of 12V ~ 24V to function in a circuit or system. Photoelectric sensors should have a response time of 1ms. As a precaution, the photoelectric sensor must operate at -25 °C degrees Celsius at all times. For reliable operation, a maximum operating temperature of 55 °C is required. In order for the photoelectric sensor to function, the 4 pins must be connected. A photoelectric sensor must have an output current of 100 mA. The photoelectric sensor is not damaged by voltage of 24 V applied in DC circuit. As low a voltage as possible, such as 0 volts, can be used for this photoelectric sensor. The photoelectric sensor supply voltage should be set to 24 V for maximum efficiency.
XUB5BPANM12 Features
Sensing Distance: 23.622" (600mm)
4 pins
Response Time: 1ms
Operating Temperature: -25°C ~ 55°C
- Series
Maximal Supply Voltage (DC): 24 V
Minimal Supply Voltage (DC): 12 V
XUB5BPANM12 Applications
There are a lot of Schneider Electric
XUB5BPANM12 Photoelectric Sensors applications.
- Counting small objects
- Detecting colours
- Monitoring bigger areas for objects with light grids
- Measuring distance
- Logistics and materials handling
- Automatic doors
- Zone scanners
- Passive infrared sensors
- Luminescence sensors
- Contrast sensors
