Manufacturer :

Microchip Technology

Product Category :

Battery Chargers

Adjustable Threshold :

yes

Analog IC - Other Type :

POWER SUPPLY SUPPORT CIRCUIT

Base Part Number :

MCP73831

Base Product Number :

MCP73831

Battery Chemistry :

Lithium Ion/Polymer

Battery Pack Voltage :

4.2V

Battery Type :

Li-Ion, Li-Pol

Brand :

Microchip Technology

Charge Current :

15 to 500 mA

Charge Current - Max :

500mA

Contact Plating :

Tin

Current - Charging :

Constant - Programmable

ECCN Code :

EAR99

Factory Lead Time :

5 Weeks

Fault Protection :

Over Voltage

Height :

0.88 mm

Input Voltage :

6V

Interface :

--

JESD-609 Code :

e3

Lead Free :

Lead Free

Length :

3mm

Manufacturer :

Microchip

Max Input Voltage :

7V

Max Supply Voltage :

6V

Maximum Operating Temperature :

+ 85 C

Mfr :

Microchip Technology

Min Supply Voltage :

3.75V

Minimum Operating Temperature :

- 40 C

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Mount :

Surface Mount

Mounting :

Surface Mount

Mounting Style :

SMD/SMT

Mounting Type :

Surface Mount

MSL :

MSL 1 - Unlimited

Nominal Input Voltage :

6V

Number of Cells :

1

Number of Channels :

1

Number of Functions :

1

Number of Pins :

8

Number of Terminations :

8

Operating Supply Current :

510μA

Operating Supply Voltage :

3.75 V to 6 V

Operating Temperature :

-40°C~85°C TA

Output Current :

500mA

Output Voltage :

4.2V

Package :

Tape and Reel (TR);Cut Tape (CT);Digi-Reel®;

Package / Case :

8-VFDFN Exposed Pad

Packaging :

Tape and Reel (TR)

Part Status :

Active

Pbfree Code :

yes

Peak Reflow Temperature (Cel) :

260

Pin Count :

8

Power Supplies :

3.3/5V

Product :

Charge Management

Product Category :

Battery Management

Product Status :

Active

Product Type :

Battery Management

Programmable Features :

Current

Published :

2004

Radiation Hardening :

No

RoHS :

Details

RoHS Status :

ROHS3 Compliant

Screening Level :

Industrial

Series :

--

Supplier Device Package :

8-DFN (2x3)

Supplier Package :

DFN EP

Supply Voltage :

5.2V

Terminal Pitch :

0.5mm

Terminal Position :

Dual

Time@Peak Reflow Temperature-Max (s) :

40

Type :

Charge Controller

Voltage - Supply (Max) :

6V

Width :

2mm
