LMD18200T
Or copy the link below:
- Mfr.Part #
- LMD18200T
- Manufacturer
- Texas Instruments
- Package / Case
- TO-220-11 (Formed Leads)
- Datasheet
- Download
- Description
- IC MTR DRV BIPLR 12-55V TO220-11
- Stock
- 16,653
- In Stock ：
- 16,653
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Texas Instruments
- Product Category :
- Motor Drivers, Controllers
- Applications :
- GENERAL PURPOSE
- Max Output Current :
- 3A
- Supply Voltage :
- 42V
- Mount :
- Through Hole
- Motor Type - Stepper :
- Bipolar
- Operating Supply Current :
- 13mA
- Interface :
- Parallel
- Lead Free :
- Contains Lead
- Max Output Voltage :
- 55V
- JESD-609 Code :
- e0
- REACH SVHC :
- No SVHC
- Input Characteristics :
- Standard
- Radiation Hardening :
- No
- Built-in Protections :
- TRANSIENT; THERMAL; UNDER VOLTAGE
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Output Configuration :
- Low Side (2)
- Terminal Finish :
- Tin/Lead (Sn/Pb)
- Output Voltage :
- 55V
- RoHS Status :
- Non-RoHS Compliant
- Voltage - Supply :
- 12V~55V
- Operating Temperature :
- -40°C~150°C TJ
- Motor Type - AC, DC :
- Brushed DC
- Number of Terminations :
- 11
- Number of Channels :
- 2
- Lifecycle Status :
- NRND (Last Updated: 4 days ago)
- Number of Pins :
- 11
- Voltage - Load :
- 12V~55V
- ECCN Code :
- EAR99
- Power Dissipation :
- 3W
- Terminal Position :
- Zig-Zag
- Package / Case :
- TO-220-11 (Formed Leads)
- Output Current Flow Direction :
- SOURCE SINK
- Mounting Type :
- Through Hole
- Function :
- Driver - Fully Integrated, Control and Power Stage
- Base Part Number :
- LMD18200
- Output Peak Current Limit-Nom :
- 6A
- Packaging :
- Tube
- Datasheets
- LMD18200T
Motor Drivers, Controllers Texas Instruments LMD18200T Overview
The Motor Drivers, Controllers Texas Instruments LMD18200T is a high-performance integrated circuit designed specifically for driving bipolar stepper motors and brushed DC motors. This robust driver IC offers advanced features to meet the demanding needs of industrial and consumer applications, providing efficient and reliable motor control. It's engineered to handle up to 55V and 3A, making it suitable for a wide range of motor-driven applications. The LMD18200T integrates full bridge outputs, thermal shutdown, and current sensing capabilities, ensuring optimal performance and safety in operation.
LMD18200T Features
This IC is packed with features designed for robust and flexible motor control. It supports up to 55V of supply voltage and 3A of output current, which is ideal for driving a wide variety of motors. The chip includes built-in protection features such as thermal shutdown, under-voltage lockout, and crossover-current protection, enhancing the safety and durability of the application. Additionally, the LMD18200T provides PWM motor control, which allows for precise control over motor speed and torque.
LMD18200T Applications
- Robotics: Utilized in driving motors for robotic arms, wheels, and actuators, where precise control and reliability are required.
- Automated machinery: Perfect for use in automated production lines and CNC machines that require accurate motor speed and position control.
- Office automation equipment: Drives motors in office devices like printers and copiers, ensuring smooth and efficient operation.
- Home appliances: Applied in smart home devices such as automated vacuum cleaners and robotic lawnmowers.
