LMD125-0018-C440-2010000

Manufacturer :

Cree LED

Product Category :

Base Product Number :

LMD125

IP Rating :

IP20

Dimming :

Triac

Efficiency :

81%

Brand :

Cree LED

Mounting Style :

Chassis Mount

RoHS :

Details

Product Type :

LED Power Supplies

Features :

-

Topology :

AC DC Converter

Product Status :

Obsolete

Current - Output (Max) :

440mA

Output Power :

18 W

Size / Dimension :

4.84 L x 3.11 W x 1.30 H (123.0mm x 79.0mm x 33.0mm)

For Use With :

LMH2-850, 1250

Voltage - Output :

37V

Length :

123 mm

Voltage - Input (Min) :

207VAC

Subcategory :

AC-DC Power Supply

Minimum Operating Temperature :

0 C

Package :

Tray

Product Category :

LED Power Supplies

Operating Temperature Range :

0 C to + 80 C

Voltage - Input (Max) :

253VAC

Packaging :

Bulk

Weight :

0.322 lb (146.06 g)

Termination Style :

Terminal Block

Width :

79 mm

Operation Mode :

Constant Voltage (CV)

Height :

33 mm

Input Voltage :

230 VAC

Number of Outputs :

1

Power (Watts) :

16 W

Manufacturer :

Cree LED

Ratings :

IP20, NEMA 410

Operating Temperature :

0°C ~ 80°C

Standard :

-

Type :

Constant Current

Maximum Operating Temperature :

+ 80 C

Mounting Type :

Chassis Mount

Approval Agency :

CE, CQC, cULus

Series :

LMD125
