LMD18400N

Manufacturer :

Texas Instruments

Product Category :

Gate Drivers

Radiation Hardening :

No

Driven Configuration :

High-Side

Package / Case :

20-DIP (0.300, 7.62mm)

JESD-609 Code :

e0

Operating Supply Voltage :

12V

Peak Reflow Temperature (Cel) :

260

Logic Voltage - VIL, VIH :

0.8V 2V

Time@Peak Reflow Temperature-Max (s) :

40

Output Current :

3.75A

Packaging :

Tube

Lead Free :

Contains Lead

ECCN Code :

EAR99

Number of Terminations :

20

Turn On Delay Time :

10 μs

Driver Number of Bits :

4

Number of Outputs :

4

Operating Temperature :

-25°C~150°C TJ

Quiescent Current :

15mA

Supply Voltage :

12V

Output Peak Current Limit-Nom :

3.75A

Pin Count :

20

Terminal Position :

Dual

Output Voltage :

5.5V

Terminal Pitch :

1.7mm

Voltage - Supply :

7V~28V

REACH SVHC :

No SVHC

Number of Pins :

20

Interface IC Type :

BUFFER OR INVERTER BASED PERIPHERAL DRIVER

Nominal Supply Current :

15mA

Terminal Finish :

Tin/Lead (Sn/Pb)

Drain to Source Resistance :

800mOhm

Current - Peak Output (Source, Sink) :

3A 3A

Number of Functions :

1

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Mounting Type :

Through Hole

RoHS Status :

Non-RoHS Compliant

Built-in Protections :

OVER VOLTAGE; THERMAL; TRANSIENT

Surface Mount :

No

Input Type :

Non-Inverting

Channel Type :

Independent

Turn-Off Delay Time :

2 μs

Base Part Number :

LMD18400

Gate Type :

N-Channel MOSFET
