2721-104/031-000

Manufacturer :

WAGO

Product Category :

Headers, Plugs and Sockets

Wire Gauge or Range - mm² :

0.2-2.5mm²

Current - IEC :

16A

Color :

Gray

Number of Contacts :

4 Pole

Insulation Height :

0.591 (15.00mm)

Current - UL :

15 A

Contact Finish :

Tin

Material contact :

Other copper alloys

Header Orientation :

-

Screw Size :

-

Connectable conductor cross section multi-wired :

0.2 - 2.5

Product Status :

Active

Temperature :

-60-100 °C

Over voltage category :

III

Ingress Protection :

-

PPAP :

No

Automotive :

No

Series :

MCSMIDI

Operating Temperature :

-60°C ~ 100°C

Wire Size :

24-12 AWG

With protective conductor :

No

Size :

24-12 AWG

Package :

Box

Torque - Screw :

-

Contact Tail Length :

-

Positions Per Level :

4

Voltage - IEC :

630 V

Stripping Length :

10-11 mm

Approvals :

CB, CSA, UR

EU RoHS :

Compliant

Termination Style :

Screwless - Push-In Spring

ECCN (US) :

EAR99

Type of electric connection :

Spring clamp connection

Housing Material :

Polyamide (PA66), Nylon 6/6

Plug Wire Entry :

180°

Contact Mating Finish :

Tin

Features :

Mounting Flange, Retention Latches (Non-Wire Side)

Inflammability class of insulation material according to with UL94 :

V0

Connectable conductor cross section fine-strand with cable end sleeve :

0.25 - 1.5

Current :

15 A

Rated current In :

16

Wire Strip Length :

10-11mm

Number of Levels :

1

Degree of protection (IP), mounted :

IP20

Material of contact surface :

Tin

Contact Material :

COPPER ALLOY

Voltage :

300 V

Material Flammability Rating :

UL94 V-0

Pollution degree :

2

Mounting Type :

Free Hanging (In-Line)

Connectable conductor cross section solid-core :

0.2 - 2.5

HTS :

8536.69.40.40

Voltage - UL :

600 V

Type :

Plug, Female Sockets

Connectable conductor cross section fine-strand without cable end sleeve :

0.2 - 2.5

Material housing :

Plastic

Manufacturer :

Wago

Pitch :

0.197 (5.00mm)

Wire Gauge or Range - AWG :

12-24 AWG

Number of Positions :

4

Rated surge voltage :

4
