3RT1926-2GD51

Manufacturer :

Siemens

Product Category :

Time Delay Relays

Mounting Type :

DIN Rail

Timing Adjustment Method :

Screwdriver Slot

Max. operating voltage :

240V

Depth :

73mm

Product Status :

Active

Contact Current Rating :

3 A

Height :

46mm

Function :

Star Delta Controller

Voltage - Supply :

200 ~ 240VAC

Number of Contacts :

2

Dim :

(W x H x D) 33 x 46 x 73 mm

Base Product Number :

3RT1926

Min. operating voltage :

200V

Timing Initiate Method :

Input Voltage

Min. temperature :

-25°C

Max. temperature :

+60°C

Mounting Style :

DIN

Range :

SIRIUS

Series :

3RT19262

Delay Time :

1.5 Sec ~ 30 Sec

Operating principle :

Electronic

Type :

3RT1926-2GD51

Number of contacts as normally open contact :

0

RoHS :

Non-Compliant

Circuit :

DPST-NO (2 Form A)

Electrical lifespan :

100000

Termination Style :

Screw Terminal

Contact Rating @ Voltage :

3A @ 250VAC

Width :

33mm

Number of contacts as normally closed contact :

0

Number of contacts as change-over contact :

0

Relay Type :

Solid State Relay

Content :

1pc(s)

Durability :

1000 0000
