53014-0412

Manufacturer :

Molex

Product Category :

Headers, Male Pins

Gender :

HDR

Mounting Option 1 :

LOCKING

Product Status :

Active

Max Voltage Rating (AC) :

125 V

Voltage Rating Max :

125V

Contact Resistance :

20 mΩ

Additional Feature :

LOW PROFILE

Contact Pattern :

RECTANGULAR

Number of Contact Rows :

1

Mating Information :

MULTIPLE MATING PARTS AVAILABLE

Body Orientation :

Straight

DIN Conformance :

No

Pitch (mm) :

2(mm)

Contact Gender :

Male

Connector Type :

Blade Pin

Total Number of Contacts :

4

Contact Material :

Phosphor Bronze

Insulator Color :

Red

Termination Method :

Solder

Manufacturer :

Molex

Mating Contact Pitch :

0.079 inch

UL Flammability Code :

94V-0

Housing Color :

Natural

Product Depth (mm) :

4.35(mm)

Mounting Style :

Through Hole

Reach Compliance Code :

Compliant

Number Of PCB Rows :

1

Mixed Contacts :

No

Current Rating (Max) :

2/Contact(A)

Package :

Bulk

Fastening Type :

DETENT

Depth :

4.35 mm

Max Operating Temperature :

85 °C

Filter Feature :

No

Orientation :

Straight

Number of Positions :

4

Contact Finish Termination :

Tin (Sn)

IEC Conformance :

No

Product Length (mm) :

10(mm)

MIL Conformance :

No

Number of Contacts :

4(POS)

Packaging :

Bag

Contact Resistance Max :

20(mohm)

Number of Rows :

1

Body Depth :

0.23 inch

Contact Plating :

TIN OVER NICKEL

Terminal Length :

0.138 inch

Mount :

Through Hole

Termination :

Solder

Mounting Type :

BOARD

RoHS :

Compliant

Pitch :

2 mm

Series :

*

Product Height (mm) :

5.85(mm)

Housing Material :

Nylon 6/6

Min Operating Temperature :

-20 °C

Termination Type :

Solder

Operating Temp Range :

-20C to 85C

Color :

Red

Terminal Pitch :

2 mm

Type :

Shrouded Header

Body Breadth :

0.171 inch

Contact Mating Length :

3.0988 mm

Subcategory :

Headers and Edge Type Connectors

JESD-609 Code :

e3

PCB Contact Pattern :

RECTANGULAR

Reliability :

COMMERCIAL

Length :

10 mm

Option :

GENERAL PURPOSE
