53253-0880

Manufacturer :

Molex

Product Category :

Headers, Male Pins

Insulation Resistance :

1000000000 Ω

PCB Contact Pattern :

RECTANGULAR

Connector Type :

BOARD CONNECTOR

Mounting Option 1 :

LOCKING

Product Height (mm) :

5.5(mm)

Operating Temp Range :

-40C to 105C

Body Depth :

0.217 inch

Type :

Shrouded Header

Contact Style :

SQ PIN-SKT

Number of Contacts :

8(POS)

Termination Type :

Solder

Housing Material :

Nylon 6/6

Contact Pattern :

RECTANGULAR

Gender :

HDR

Housing Color :

Natural

Contact Material :

Brass

Package :

Box

Body Breadth :

0.144 inch

Product Length (mm) :

18(mm)

Contact Plating :

Tin

Terminal Length :

0.091 inch

Number of Contact Rows :

1

Packaging :

Tray

Product Status :

Active

Series :

*

Product Depth (mm) :

3.65(mm)

Number Of PCB Rows :

1

Contact Resistance Max :

20(mohm)

Mounting Type :

BOARD

Reference Standard :

UL

Body Orientation :

Straight

Reliability :

COMMERCIAL

Terminal Pitch :

2.0066 mm

Voltage Rating Max :

125V

Contact Resistance :

20 mΩ

Current Rating (Max) :

2/Contact(A)

Pitch (mm) :

2(mm)

ECCN Code :

EAR99

Termination Method :

Solder

Subcategory :

Headers and Edge Type Connectors

HTS Code :

8536.69.40.40

Manufacturer :

Molex

Mounting Style :

Through Hole

Contact Gender :

Male

Mating Contact Pitch :

0.079 inch

Total Number of Contacts :

8

Reach Compliance Code :

Compliant
