68-2

Manufacturer :

Signal Transformer

Product Category :

Power Transformers

Moisture Sensitivity Level (MSL) :

Not Applicable

Size / Dimension :

104.80mm Lx85.70mm W

Center Tap :

yes

Secondary Winding(s) :

Dual

Voltage - Primary :

105V 115V 125V

Additional Feature :

THE TWO SECONDARIES HAVE CENTER TAPPED CONNECTIONS

Output Voltage 2 :

34V

Reach Compliance Code :

Unknown

Type :

Laminated Core

ECCN Code :

EAR99

Primary Rating :

SINGLE 115V

Height Seated (Max) :

87.30mm

Termination Style :

Solder, Quick Connect

Width :

85.7mm

Mounting Type :

Chassis Mount

Physical Dimension :

104.8mm X 85.7mm X 87.3mm

RoHS Status :

ROHS3 Compliant

Factory Lead Time :

16 Weeks

Termination :

Solder

Voltage - Secondary (Full Load) :

Parallel 34V Series 68V

Mount :

Chassis Mount

Output Voltage 1 :

34V

Power - Max :

136VA

Length :

104.8mm

Max Power Dissipation :

136W

Voltage - Isolation :

1500Vrms

Max Output Current :

2A

Primary Winding(s) :

Single, Multiple Taps

Weight :

6.8lbs 3.1kg

Current - Output (Max) :

Parallel 4A Series 2A
