734-104/037-000

Manufacturer :

WAGO

Product Category :

Headers, Plugs and Sockets

Number of Positions :

4

Width :

25.80mm

Material housing :

Plastic

Rated surge voltage :

2.5

Pins per row :

4

Header Orientation :

-

No. of rows :

1

Contact Material :

COPPER ALLOY

Reach Compliance Code :

Compliant

Degree of protection (IP), mounted :

IP20

Voltage - IEC :

320 V

Over voltage category :

III

Height :

18.60mm

Type of electric connection :

Spring clamp connection

Approvals :

CCA

Contact Tail Length :

-

Length :

13.40mm

Operating Temperature :

-60°C ~ 100°C

Contact Mating Finish :

Tin

ECCN Code :

EAR99

Housing Material :

Polyamide (PA66), Nylon 6/6

Wire Gauge or Range - AWG :

14-28 AWG

PPAP :

No

Number of Contacts :

4 Pole

With protective conductor :

No

Connectable conductor cross section multi-wired :

0.08 - 1.5

AWG max. :

14

Connection :

Spring-loaded terminal

Nominal current - rounded value :

10A

Ingress Protection :

-

Manufacturer :

Wago

Automotive :

No

AWG (min.) :

28

EU RoHS :

Compliant

Connector contact surface :

Tin plated

Current - UL :

10 A

Wire Size :

28-14 AWG

Pitch :

0.138 (3.50mm)

Pollution degree :

2

Current :

10 A

Case material :

PA 66

Insulation Height :

0.528 (13.40mm)

Voltage :

300 V

Rad Hardened :

No

HTS :

8536.69.40.40

Number of Levels :

1

Connectable conductor cross section solid-core :

0.08 - 1.5

Material of contact surface :

Tin

Wire Gauge or Range - mm² :

0.08-1.5mm²

Product Status :

Active

Material contact :

Other copper alloys

Material Flammability Rating :

UL94 V-0

Packaging :

Box

Nominal current :

10A

Inflammability class of insulation material according to with UL94 :

V0

Dim :

(L x W x H) 13.40 x 25.80 x 18.60 mm

Content :

100pc(s)

max. cross section :

1.5mm²

Rated current In :

10

Terminal and Terminal Block Type :

BARRIER STRIP TERMINAL BLOCK

Current - IEC :

10A

HTS Code :

8536.69.40.40

Mounting Type :

Free Hanging (In-Line)

Industrial packaging :

yes

Connectable conductor cross section fine-strand with cable end sleeve :

0.25 - 1.5

Stripping Length :

6-7 mm

Color :

Gray

Stripping length (max.) :

7.00mm

Type :

WAGO GmbH and Co. KG

Total number of pins :

4

Plug Wire Entry :

180°

Screw Size :

-

Voltage - UL :

300 V

Package :

Box

Size :

28-14 AWG

Positions Per Level :

4

CS :

3.50mm

Min. cross section :

0.08mm²

Connectable conductor cross section fine-strand without cable end sleeve :

0.08 - 1.5

Series :

734

Wire Strip Length :

6-7mm

Temperature :

-60-100 °C

Contact Finish :

Tin

Torque - Screw :

-

Nominal voltage :

300V

Termination Style :

Screwless - Push-In Spring

ECCN (US) :

EAR99

Features :

+ lateral latch

Manufacturer part # :

734-104/037-000
