788-305

Manufacturer :

WAGO

Product Category :

Power Relays, Over 2 Amps

Number of contacts as change-over contact :

1

Switching current (max.) :

16A

Mounting Type :

DIN Rail

Operating Temperature :

-40° ~ 70°C

Features :

Lighted Indicator

Durability :

30 x 106 switching operations

Height :

54mm

Termination Style :

Spring Terminal

Switching Voltage :

250VAC - Max

Contact Rating (Current) :

16 A

Content :

1pc(s)

Length :

86mm

Series :

788

Nominal current (details) :

16A

Nominal voltage (details) :

48V DC

Nominal voltage :

48V DC

Contact Material :

Silver Nickel (AgNi)

Voltage type for actuating :

DC

Max. switching capacity :

4000VA

Package :

Box

Rated control supply voltage at DC :

48 - 48

Type :

788-305

Operate Time :

8 ms

Min. temperature :

-25°C

Material of contact surface :

Silver

Ambient temperature :

-25 - +50°C

Coil Voltage :

48VDC

Degree of protection (IP) :

IP20

Number of contacts as normally open contact :

0

Product Status :

Active

Number of contacts as normally closed contact :

0

With detachable clamps :

No

Type of electric connection :

Spring clamp connection

Coil Current :

11 mA

Release Time :

6 ms

Switching voltage (max.) :

250V AC

Max. temperature :

+50°C

Dim :

(L x W x H) 86 x 15 x 54 mm

Depth :

86

Coil Type :

Non Latching

Nominal current :

16

Width :

15mm

Contact Form :

SPDT (1 Form C)
