788-355

Manufacturer :

WAGO

Product Category :

Power Relays, Over 2 Amps

Height :

64mm

Material of contact surface :

Tin

Coil Voltage :

24VDC

Termination :

Cage Clamp

Ambient temperature :

-25 - +50°C

Switching current (max.) :

16A

Number of contacts as normally closed contact :

0

Mounting Type :

DIN Rail

Package :

Box

Min. temperature :

-25°C

Approvals :

UL

Rated control supply voltage at DC :

24 - 24

RoHS :

yes

Contact Material :

Silver Tin Oxide (AgSnO)

Durability :

30 x 106 switching cycles

Type of electric connection :

Spring clamp connection

Coil Type :

Non Latching

Contact Rating (Current) :

16 A

Degree of protection (IP) :

IP20

Nominal voltage :

24V dc

Operate Time :

8 ms

Enclosure :

Plastic

Number of contacts as change-over contact :

0

With detachable clamps :

No

Coil Current :

21.8 mA

Relay Type :

GENERAL PURPOSE

Release Time :

2 ms

Max. switching capacity :

4000VA

Series :

788

Dim :

(L x W x H) 86 x 15 x 64 mm

Depth :

86

Product Status :

Active

Type :

788-355

Width :

15mm

Length :

86mm

Nominal current :

16

Switching Voltage :

250VAC - Max

Operating Temperature :

-40° ~ 70°C

Features :

Lighted Indicator

Contacts :

1NO

Nominal current (details) :

16A

Number of contacts as normally open contact :

1

Voltage type for actuating :

DC

Mounting :

DIN Rail

Content :

1pc(s)

Max. temperature :

+50°C

Switching voltage (max.) :

250V AC

Manufacturer :

Wago

Nominal voltage (details) :

24V dc

Termination Style :

Spring Terminal
