788-546

Manufacturer :

WAGO

Product Category :

Power Relays, Over 2 Amps

Operating Temperature :

-40° ~ 70°C

Number of contacts as normally closed contact :

0

Relay Type :

GENERAL PURPOSE

Type of electric connection :

Spring clamp connection

Degree of protection (IP) :

IP20

Coil Voltage :

24VDC

Series :

788

Number of contacts as change-over contact :

2

Depth :

73

Material of contact surface :

Nickel

Package :

Box

Voltage type for actuating :

AC

With detachable clamps :

No

Features :

Lighted Indicator

Termination Style :

Spring Terminal

Contact Rating (Current) :

8 A

Rated control supply voltage at AC 60 Hz :

24 - 24

Product Status :

Active

Nominal current :

8

Coil Current :

31.6 mA

Operate Time :

15 ms

Mounting Type :

DIN Rail

Width :

15

Height :

86

Number of contacts as normally open contact :

0

Rated control supply voltage at AC 50 Hz :

24 - 24

Contact Material :

Silver Nickel (AgNi)

Switching Voltage :

250VAC - Max

Release Time :

8 ms

Contact Form :

DPDT (2 Form C)
