AZ2850-2A-12DE

Manufacturer :

American Zettler

Product Category :

Power Relays, Over 2 Amps

Must Release Voltage :

1.2 VDC

Input Switching Control Type :

Random

Features :

-

Operating Temperature :

-40°C ~ 85°C

Termination :

PC Pin

Max Voltage Rating (DC) :

30 V

Electrical Life :

100000 Cycle(s)

Mount :

Through Hole

Base Product Number :

AZ2850

Max Operating Temperature :

85 °C

End Contact Material :

Silver Cadmium Oxide

Body Height :

26.4 mm

Mounting Type :

Through Hole

Termination Style :

PC Pin

Min Operating Temperature :

-40 °C

Dielectric Strength Between Coil and Contacts :

4000 Vrms

Coil Resistance :

86 Ω

Max Current Rating :

30 A

Package :

Tray

Body Breadth :

34.8 mm

Terminal Length :

0.0084 inch

Body Length or Diameter :

52.6 mm

Relay Type :

POWER/SIGNAL RELAY

Product Status :

Active

Coil Voltage(DC)-Max :

20.7 V

Insulation Resistance :

1000000000 Ω

Coil/Input Supply Type :

DC

Reach Compliance Code :

Compliant

Series :

-

Contact Rating (Current) :

40 A

Contact Material :

Cadmium, Silver

Max Voltage Rating (AC) :

600 V

Relay Action :

LATCHED

Operate Time :

15 ms

Contact Resistance :

50 mΩ

Relay Form :

2 FORM A

Coil Type :

Non Latching

Number of Pins :

6

Lead Free :

Lead Free

Must Operate Voltage :

9 VDC

Weight :

86 g

Physical Dimension :

52.6mm x 34.8mm x 26.4mm

ECCN Code :

EAR99

Termination Type :

Solder

RoHS :

Compliant

Coil Voltage (DC) :

12 V

Coil Operate Voltage(DC) :

9 V

Contact/Output Supply Type :

AC/DC

Sealing :

Epoxy

Throw Configuration :

DPST

Coil Voltage :

12VDC

Release Time :

10 ms

Number of Terminals :

16

Relay Function :

DPST

Coil Current :

140 mA

Coil Insulation :

Class F

Reference Standard :

UL; VDE

Switching Voltage :

600VAC, 30VDC - Max

Seal Rating :

Sealed - Fully

Contact Form :

DPST-NO (2 Form A)

Dielectric Strength Between Open Contacts :

1500 Vrms

PCB Hole Count :

16
