BCM62B,215

Manufacturer :

Nexperia

Product Category :

Transistors - Special Purpose

REACH SVHC :

No SVHC

Base Part Number :

BCM62B

Collector Emitter Saturation Voltage :

-200mV

Zener Voltage :

2.4V

JESD-609 Code :

e3

Collector Base Voltage (VCBO) :

-50V

Frequency :

175MHz

Test Current :

5mA

Lead Free :

Lead Free

Ambient Temperature Range High :

150°C

Power Dissipation :

390mW

Published :

2009

Case Connection :

COLLECTOR

Applications :

Current Mirror

Collector Emitter Breakdown Voltage :

-45V

Min Operating Temperature :

-65°C

Packaging :

Tape and Reel (TR)

Current Rating :

100mA

Transistor Application :

AMPLIFIER

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Height :

1.1mm

Mounting Type :

Surface Mount

Max Junction Temperature (Tj) :

150°C

Transition Frequency :

175MHz

Gain Bandwidth Product :

175MHz

Factory Lead Time :

4 Weeks

Voltage - Rated :

45V

DC Current Gain-Min (hFE) :

200

Terminal Form :

Gull wing

Number of Pins :

4

Package / Case :

TO-253-4, TO-253AA

Radiation Hardening :

No

Mount :

Surface Mount

Polarity :

PNP

Contact Plating :

Tin

Collector Emitter Voltage (VCEO) :

-45V

Max Operating Temperature :

150°C

Number of Terminations :

4

Number of Elements :

2

Emitter Base Voltage (VEBO) :

-5V

Pin Count :

4

Transistor Type :

2 PNP (Dual) Current Mirror

Max Collector Current :

-100mA

Element Configuration :

Dual

Max Power Dissipation :

390mW

RoHS Status :

ROHS3 Compliant

hFE Min :

200

Tolerance :

5%
