EC2-12NU

Manufacturer :

KEMET

Product Category :

Signal Relays, Up to 2 Amps

Dielectric Strength Between Open Contacts :

1000

Electrical Life :

1000000

Insulation Resistance :

1000000000

Terminal Length :

.003

Contact/Output Supply Type :

AC/DC

Input Switching Control Type :

Random

Coil Power :

140

End Contact Material :

Silver Alloy

Coil Release Voltage(DC) :

1.2

Contact Material :

Silver

Packing Method :

Tube

Coil Resistance :

1028

Series :

EC2

Body Breadth :

7.5

Throw Configuration :

DPDT

Dielectric Strength Between Coil and Contacts :

1500

Mounting Feature :

THROUGH HOLE-STRAIGHT MOUNT

Contact Resistance :

50

Release Time :

1

Body Height :

9.4

Weight :

1.9

Relay Form :

2 Form C

Coil Current(DC)-Max :

.012

Contact Current(DC)-Max :

2

Relay Function :

DPDT

Coil/Input Supply Type :

DC

Relay Action :

Momentary

Physical Dimension :

15mm x 7.5mm x 9.4mm

Contact Voltage(AC)-Max :

125

Operate Time :

2

PCB Hole Count :

8

Coil Voltage(DC)-Max :

12

Contact Current(AC)-Max :

.5

Relay Type :

POWER/SIGNAL RELAY

Number of Terminals :

8

Contact Voltage(DC)-Max :

30

Reference Standard :

CSA; EN; IEC; TUV; UL

End Contact Plating :

GOLD ALLOY

Body Length or Diameter :

15

Termination Type :

Solder

Coil Operate Voltage(DC) :

9

RoHS :

Non-Compliant

REACH SVHC :

No SVHC
