ES1J

Manufacturer :

HY Electronic (Cayman) Limited

Product Category :

Diodes - Rectifiers - Single

Peak Non-Repetitive Surge Current :

30A

Lead Free :

Lead Free

Packaging :

Tape and Reel (TR)

Length :

4.6mm

Speed :

Fast Recovery =< 500ns, > 200mA (Io)

Forward Current :

1A

Recovery Time :

35 ns

Factory Lead Time :

10 Weeks

Mount :

Surface Mount

Radiation Hardening :

No

Voltage - Forward (Vf) (Max) @ If :

1.7V @ 1A

REACH SVHC :

No SVHC

Current - Reverse Leakage @ Vr :

5µA @ 600V

Capacitance @ Vr, F :

8pF @ 0V 1MHz

Element Configuration :

Single

Operating Temperature - Junction :

150°C Max

Max Junction Temperature (Tj) :

150°C

Published :

2006

Average Rectified Current :

1A

Height :

2.5mm

Reverse Recovery Time :

35 ns

Package / Case :

DO-214AC, SMA

Reverse Voltage :

600V

Forward Voltage :

1.7V

Termination :

SMD/SMT

Min Operating Temperature :

-55°C

Peak Reverse Current :

5μA

Base Part Number :

ES1J

Mounting Type :

Surface Mount

Voltage :

600V

Max Operating Temperature :

150°C

Lifecycle Status :

ACTIVE (Last Updated: 4 days ago)

Current - Average Rectified (Io) :

1A

Capacitance :

10pF

Supplier Device Package :

SMA (DO-214AC)

Width :

2.896mm

Max Repetitive Reverse Voltage (Vrrm) :

600V

Contact Plating :

Tin

Current :

1A

Number of Pins :

2

RoHS Status :

ROHS3 Compliant

Max Surge Current :

30A

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Voltage - DC Reverse (Vr) (Max) :

600V

Diode Type :

Standard

Max Reverse Voltage (DC) :

600V

Max Forward Surge Current (Ifsm) :

30A
