NRF52832-QFAA-R7

Manufacturer :

Nordic Semiconductor

Product Category :

RF Transceiver ICs

Current - Receiving :

5.4mA

Width :

6mm

Height Seated (Max) :

0.95mm

Modulation :

GFSK

Packaging :

Tape and Reel (TR)

Number of Terminations :

48

RF Family/Standard :

Bluetooth

Surface Mount :

yes

Number of Functions :

1

Sensitivity :

-96dBm

RoHS Status :

ROHS3 Compliant

Package / Case :

48-VFQFN Exposed Pad

Power - Output :

4dBm

Serial Interfaces :

I2S, SPI, UART

Voltage - Supply :

1.7V~3.6V

Operating Temperature (Min) :

-40°C

Operating Temperature (Max) :

85°C

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Frequency :

2.4GHz

Terminal Position :

QUAD

Supply Voltage :

3V

JESD-30 Code :

S-XQCC-N48

Factory Lead Time :

20 Weeks

Temperature Grade :

Industrial

HTS Code :

8542.39.00.01

Published :

2016

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

Moisture Sensitivity Level (MSL) :

2 (1 Year)

Terminal Form :

NO LEAD

Mounting Type :

Surface Mount

Current - Transmitting :

7.5mA

Terminal Pitch :

0.4mm

Protocol :

ANT, Bluetooth v5.0

Memory Size :

512kB Flash 64kB RAM

Data Rate (Max) :

2Mbps

Type :

TxRx + MCU

Length :

6mm

GPIO :

32
