PC-12-70

Manufacturer :

Signal Transformer

Product Category :

Power Transformers

Length :

25.4mm

Moisture Sensitivity Level (MSL) :

Not Applicable

Height :

21.1mm

Current - Output (Max) :

Parallel 140mA Series 70mA

Size / Dimension :

25.40mm Lx34.92mm W

Power - Max :

1VA

Width :

34.92mm

Voltage - Primary :

115V

Voltage - Isolation :

1500Vrms

Additional Feature :

OPERATING FREQUENCY: 50-500 HZ

Factory Lead Time :

18 Weeks

Max Power Dissipation :

1W

Termination Style :

PC Pin

Weight :

0.157lb 71.21g

ECCN Code :

EAR99

VA Rating :

1 VA

Output Power :

1.75kW

Published :

2009

Height Seated (Max) :

21.08mm

Secondary Winding(s) :

Dual

Primary Winding(s) :

Single

Output Voltage 2 :

6.3V

Lead Free :

Lead Free

Mounting Type :

Through Hole

RoHS Status :

ROHS3 Compliant

Type :

Laminated Core

Approval Agency :

UL; CSA

Center Tap :

No

Operating Frequency-Max :

0.5kHz

Series :

PC

Max Output Current :

70mA

Termination :

PC Pin

Mount :

Through Hole

Voltage - Secondary (Full Load) :

Parallel 6.3V Series 12.6V

Output Voltage 1 :

6.3V

HTS Code :

8504.31.40.35

Operating Frequency-Min :

0.05kHz
