PMB2153330KVR

Manufacturer :

Nichicon

Product Category :

Film Capacitors

Series :

PMB

Operating Temperature :

-40°C ~ 85°C

Applications :

High Frequency, Switching; High Pulse, DV/DT; Snubber

Package :

Bulk

Termination :

Screw Terminals

Subcategory :

Capacitors

Lead Spacing :

-

Height - Seated (Max) :

1.083" (27.50mm)

Minimum Operating Temperature :

- 40 C

Length :

42.5 mm

Ratings :

-

Features :

-

Voltage Rating - DC :

1500V (1.5kV)

ESR (Equivalent Series Resistance) :

4.6 mOhms

Capacitance :

0.33 µF

Product :

Snubber Film Capacitors

Product Status :

Active

Width :

24.5 mm

Packaging :

Bulk

Manufacturer :

Nichicon

Maximum Operating Temperature :

+ 85 C

Brand :

Nichicon

Number of Pins :

2 Pin

ESR :

4.6 mOhms

Type :

High Current

Height :

27.5 mm

Dielectric :

Polypropylene (PP)

Product Type :

Film Capacitors

Tolerance :

±10%

Product Category :

Film Capacitors

RoHS :

Details

Termination Style :

Lug

Voltage Rating - AC :

650V

Size / Dimension :

1.673" L x 0.965" W (42.50mm x 24.50mm)

Dielectric Material :

Polypropylene (PP), Metallized
