PX1004
Or copy the link below:
- Mfr.Part #
- PX1004
- Manufacturer
- RFMi
- Package / Case
- 12-SMD, No Lead
- Datasheet
- Download
- Description
- FILTER,PX,82.200 MHZ
- Stock
- 1,730
- In Stock ：
- 1,730
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- RFMi
- Product Category :
- SAW Filters
- Height (Max) :
- 0.079 2.00mm
- RoHS Status :
- ROHS3 Compliant
- Min Operating Temperature :
- -20°C
- Max Operating Temperature :
- 70°C
- Mount :
- Surface Mount
- Applications :
- Cellular, TDMA
- Packaging :
- Tape and Reel (TR)
- Bandwidth :
- 25kHz
- Mounting Type :
- Surface Mount
- Insertion Loss :
- 3dB
- Lifecycle Status :
- TO BE DISCONTINUED (Last Updated: 3 weeks ago)
- Height :
- 2.0066mm
- Termination :
- SMD/SMT
- Frequency - Cutoff or Center :
- 82.2MHz
- Length :
- 13.3096mm
- Width :
- 6.5024mm
- Lead Free :
- Lead Free
- Frequency :
- 82.2MHz
- Size / Dimension :
- 0.524Lx0.256W 13.31mmx6.50mm
- Number of Pins :
- 12
- Load Impedance :
- 50Ohm
- Radiation Hardening :
- No
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Impedance :
- 50Ohm
- Package / Case :
- 12-SMD, No Lead
- Voltage - Rated :
- 30V
- Insertion Loss (dB) :
- 3 dB
- Datasheets
- PX1004
PX1004 datasheet pdf and SAW Filters product details from Murata Electronics stock available at
