SMAJ100

Manufacturer :

Meritek

Product Category :

Mount :

Surface Mount

Length :

5.28mm

Min Operating Temperature :

-55°C

Power Line Protection :

No

Voltage - Reverse Standoff (Typ) :

100V

Package / Case :

DO-214AC, SMA

Operating Temperature :

-65°C~150°C TJ

Clamping Voltage :

162V

Height :

2.29mm

Number of Elements :

1

Voltage - Rated DC :

100V

Max Breakdown Voltage :

123V

Power Rating :

400W

Polarity :

Unidirectional

Width :

2.79mm

Voltage - Clamping (Max) @ Ipp :

162V

Direction :

Unidirectional

Termination :

SMD/SMT

Reverse Standoff Voltage :

100V

Power Dissipation :

400W

RoHS Status :

ROHS3 Compliant

Unidirectional Channels :

1

Number of Channels :

1

Mounting Type :

Surface Mount

Packaging :

Tape and Reel (TR)

Series :

SMAJ

Max Power Dissipation :

3.3W

Leakage Current :

1μA

Peak Pulse Power :

400W

Current - Peak Pulse (10/1000μs) :

2.5A

Max Surge Current :

2.5A

Reverse Breakdown Voltage :

111V

Breakdown Voltage :

111V

Factory Lead Time :

18 Weeks

Voltage - Breakdown (Min) :

111V

Type :

Zener

Power - Peak Pulse :

400W

Supplier Device Package :

DO-214AC (SMA)

Test Current :

1mA

REACH SVHC :

No SVHC

Composition :

Zener

Number of Pins :

2

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Operating Supply Voltage :

100V

Applications :

GENERAL PURPOSE

Number of Unidirectional Channels :

1

Published :

2009

Peak Pulse Current :

2.5A

Max Operating Temperature :

150°C

Lead Free :

Lead Free
