SSP3A250BDT

Manufacturer :

Schneider Electric

Product Category :

Solid State Relays

Mounting Style :

Panel Mount

Contact Configuration :

3P-NO

Output Device :

SCR

Operating Temperature Range :

-40 → +80°C

Output Voltage :

48-530 VAC

Load Current :

50 A

Termination Style :

Screw Terminal

Terminal Type :

Screw

Output Type :

AC, Zero Cross

Series :

Harmony

Mounting Type :

Chassis Mount

Number of Poles :

3

Width :

79.8 mm

Subcategory :

Relays

Nominal Output Voltage :

48 VAC, 120 VAC, 208 VAC, 240 VAC, 277 VAC, 347 VAC, 380 VAC, 415 VAC, 480 VAC, 575 VAC

Package :

Box

Depth :

97.8mm

Type :

SSR

Capacitance :

8pF

Maximum Operating Temperature :

+ 80 C

Current Rating :

50 A

Circuit :

SPST-NO (1 Form A)

Voltage - Load :

48 V ~ 530 V

Voltage - Input :

4 ~ 32VDC

Mounting :

Surface

Standards Met :

CE, CSA, UL

Input Signal :

4-32 VDC

Length :

101.3mm

Brand :

Schneider Electric

Height :

35.5mm

Product Type :

SSR - Solid State Relays

Input Polarity :

DC

Product Category :

Solid State Relays - Industrial Mount

Special Features :

For Robust Applications Requiring Considerable Heat Dissipation, SSP and SSRP Ranges Panel Mount Individually

Product :

Three Phase Relays

Minimum Operating Temperature :

- 40 C

IP Rating :

IP20

Package / Case :

Module

Dimensions :

101.3 x 97.8 x 35.5mm

Relay Type :

Three Channel Three Phase

RoHS :

Details

Manufacturer :

Schneider Electric

Switching Mode :

Zero Crossing

Termination :

Screw Terminal

Input Current :

24 mA to 35 mA

Number of Circuits :

3

Product Status :

Active
