TR35JBC220R

Manufacturer :

Stackpole Electronics, Inc.

Product Category :

Through Hole Resistors

Size / Dimension :

0.400 L x 0.181 W (10.16mm x 4.60mm)

Package :

Bulk

Rated Power Dissipation (P) :

2.5

Tolerance :

5 %

Packaging :

Bulk

Package Length :

10.16

JESD-609 Code :

e3

Operating Temperature :

-65°C ~ 175°C

Series :

TR

Package / Case :

TO-220-2

Mounting Feature :

THROUGH HOLE MOUNT

Height - Seated (Max) :

0.762 (19.36mm)

Rated Temperature :

25

Product Status :

Active

Termination Style :

Radial

Length :

10.16 mm

Additional Feature :

NON-INDUCTIVE, RATED POWER DISSIPATION USING HEATSINK: 35W

Composition :

Thick Film

Working Voltage :

350

Number of Terminals :

2

Failure Rate :

-

Mount :

Radial, Through Hole

RoHS :

Non-Compliant

Terminal Shape :

Flat

Temperature Coefficient :

50

Resistor Type :

FIXED RESISTOR

Height :

15 mm

Resistance :

220

Voltage Rating :

350 V

Size Code :

4017

Power (Watts) :

35W

Min Operating Temperature :

-65 °C

Maximum Operating Temperature :

+ 175 C

Package Height :

14.75

Supplier Device Package :

TO-220

Technology :

Thick Film

Product Type :

Thick Film Resistors

Application :

High Power

Power Rating :

35 W

Packing Method :

Bulk

Minimum Operating Temperature :

- 65 C

Lead Spacing :

5.08

Max Operating Temperature :

175 °C

Lead Length :

13.7

Subcategory :

Resistors

Features :

Moisture Resistant, Non-Inductive

Number of Terminations :

2

Width :

4.6 mm

Terminal Finish :

Matte Tin (Sn)

Package Shape :

RECTANGULAR PACKAGE

Mounting Style :

PCB Mount

Construction :

RECTANGULAR

Package Width :

4.44
