BSO051N03MSGXUMA1

Manufacturer :

Infineon Technologies

Product Category :

Transistors - FETs, MOSFETs - Single

Supplier Device Package :

PG-DSO-8

Operating Temperature :

-55°C ~ 150°C

Current - Continuous Drain (Id) @ 25°C :

14A

Channel Type :

N

Operating Mode :

ENHANCEMENT MODE

DS Breakdown Voltage-Min :

30 V

Rds On (Max) @ Id, Vgs :

5.1mOhm @ 18A, 10V

Transistor Application :

SWITCHING

Drain-source On Resistance-Max :

0.0051 Ω

Transistor Element Material :

SILICON

Terminal Form :

Gull wing

Surface Mount :

yes

Number of Elements :

1

JESD-30 Code :

R-PDSO-G8

Package Shape :

RECTANGULAR

ECCN Code :

EAR99

Terminal Position :

Dual

Drain to Source Voltage (Vdss) :

30 V

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Vgs (Max) :

±20V

Product Status :

Active

Manufacturer :

Infineon Technologies AG

Number of Terminals :

8

Reach Compliance Code :

Compliant

Vgs(th) (Max) @ Id :

2V @ 250μA

Power Dissipation :

1.56

Factory Lead Time :

1 Week

Package :

Bulk

Polarity/Channel Type :

N-Channel

Power Dissipation (Max) :

2.5W

FET Type :

N-Channel

Configuration :

SINGLE WITH BUILT-IN DIODE

Package / Case :

8-SOIC (0.154", 3.90mm Width)

Drive Voltage (Max Rds On, Min Rds On) :

-

FET Feature :

-

Mounting Type :

Surface Mount

FET Technology :

METAL-OXIDE SEMICONDUCTOR

Input Capacitance (Ciss) (Max) @ Vds :

3200 pF @ 15 V

Series :

OptiMOS?3 M

Continuous Drain Current Id :

14
