2716-102

Manufacturer :

WAGO

Product Category :

Wire to Board

Operating Temperature :

-60°C ~ 105°C

Temperature Range :

-76 to 221 Degrees F

Color :

Gray

Clamp Material - Plating :

Steel - Nickel Plated

Package :

Box

Rated Voltage :

320V

Over voltage category :

III

Mounting Type :

PCB Mount

Voltage :

300 V

Number of Levels :

1

Wire Termination :

Screwless - Leg Spring, Push-In Spring

Mating Orientation :

Horizontal with Board

Number of Poles :

2

Screw Thread :

-

Inflammability class of insulation material according to with UL94 :

V0

Connectable conductor cross section multi-wired :

1.5 - 16

Connection Type :

Spring Clamp

Manufacturer :

Wago

RoHS :

yes

Contact Material - Plating :

Electrolytic Copper - Tin Plated

Height :

28.8

Type of fastening :

Solder

Packaging type :

Other

Pin Length :

4.5 MilliMeters

Pitch :

0.394 (10.00mm)

Rated surge voltage :

4

Connectable conductor cross section fine-strand without cable end sleeve :

1.5 - 16

Positions Per Level :

2

Connectable conductor cross section solid-core :

1.5 - 16

Current :

55 A

Rated Current :

76A

Torque - Screw :

-

Features :

Lever Actuated

Screw Material - Plating :

-

Wire Gauge :

6-16 AWG

Composition :

Polyamide

Connectable conductor cross section fine-strand with cable end sleeve :

1.5 - 10

Pollution degree :

2

Series :

-

Housing Material :

Polyamide (PA66), Nylon 6/6

Approvals :

CSA;UL

Product Status :

Active

Rated current In :

76
