714-103

Manufacturer :

WAGO

Product Category :

Headers, Plugs and Sockets

Plug Wire Entry :

180°

Maximum Operating Temperature (°C) :

100

Terminal Pitch (mm) :

3.5

Maximum Current Rating (A) :

8

Type :

PC Terminal Block

Material Flammability Rating :

UL94 V-0

Housing Color :

Black

Termination Method :

Spring Clamp

Ingress Protection :

-

Wire Gauge or Range - AWG :

16-24 AWG

Housing Material :

Polyamide

Torque - Screw :

-

Number of Ports :

3

Number of Rows :

1

Inflammability class of insulation material according to with UL94 :

V0

Number of Levels :

1

Contact Mating Finish :

Tin

Height :

7.8

Connectable conductor cross section multi-wired :

0.2 - 1.5

Wire Strip Length :

9-10mm

Color :

Black

EU RoHS :

Compliant

Operating Temperature :

-60°C ~ 100°C

Mounting Type :

Free Hanging (In-Line)

Transparent :

No

Connectable conductor cross section fine-strand with cable end sleeve :

0.25 - 0.75

HTS :

8536.69.40.40

Connectable conductor cross section fine-strand without cable end sleeve :

0.2 - 1.5

Number of Positions :

3

Manufacturer :

Wago

Connectable conductor cross section solid-core :

0.2 - 1.5

Pitch :

3.5mm

Width :

3.5

Series :

MCSMINI SL

Screw Size :

-

Header Orientation :

-

Features :

-

Minimum Operating Temperature (°C) :

-60

ECCN (US) :

EAR99

Length :

7.8

Depth :

23

Wire Type :

Solid Wire;Stranded Wire

Wire Gauge or Range - mm² :

0.2-1.5mm²

Current - IEC :

8A

PPAP :

No

Positions Per Level :

3

Contact Material :

COPPER ALLOY

Automotive :

No

Product Status :

Active

Number of Circuits :

3

Rated current In :

8

Maximum Voltage Rating :

150V

Current - UL :

8 A

Insulation Height :

0.307 (7.80mm)

Package :

Box

Gender :

F

Number of Contacts :

3

Voltage - IEC :

320 V

Voltage - UL :

150 V

Contact Tail Length :

-

Termination Style :

Screwless - Leg Spring, Push-In Spring
