UCC5606DPTR
Or copy the link below:
- Mfr.Part #
- UCC5606DPTR
- Manufacturer
- Unitrode
- Package / Case
- 16-SOIC (0.154, 3.90mm Width)
- Datasheet
- Download
- Description
- SCSI TERMINATOR, 9-LINE, 110OHM,
- Stock
- 28,551
- In Stock ：
- 28,551
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Unitrode
- Product Category :
- Signal Terminators
- Terminal Finish :
- Nickel/Palladium/Gold (Ni/Pd/Au)
- Type :
- SCSI
- Height Seated (Max) :
- 1.75mm
- Pull-up Resistance-Nom :
- 110Ohm
- Terminal Form :
- Gull wing
- Operating Temperature :
- 0°C~70°C
- Voltage - Supply :
- 2.7V~5.25V
- Packaging :
- Tape and Reel (TR)
- RoHS Status :
- ROHS3 Compliant
- Pin Count :
- 16
- Lead Free :
- Contains Lead
- Resistance :
- 110Ohm
- Terminal Position :
- Dual
- Mount :
- Surface Mount
- Number of Functions :
- 1
- Weight :
- 156.489368mg
- Terminal Pitch :
- 1.27mm
- Package / Case :
- 16-SOIC (0.154, 3.90mm Width)
- Operating Supply Current :
- 218mA
- Base Part Number :
- UCC5606
- Differential Output :
- No
- Number of Terminations :
- 9
- Mounting Type :
- Surface Mount
- JESD-609 Code :
- e4
- Power Supplies :
- 3.3V
- Supply Voltage :
- 3.3V
- Radiation Hardening :
- No
- Moisture Sensitivity Level (MSL) :
- 2 (1 Year)
- Pbfree Code :
- No
- Peak Reflow Temperature (Cel) :
- 260
- Number of Signal Lines :
- 9
- Number of Pins :
- 16
- Datasheets
- UCC5606DPTR
Signal Terminators Unitrode UCC5606DPTR Overview
The Signal Terminators Unitrode UCC5606DPTR SCSI terminator is a pivotal component in maintaining signal integrity in multi-line network environments. This high-performance part features nine lines and is built around a robust 110 ohm resistance specification, ensuring minimal signal reflection and optimum termination. Ideal for complex SCSI bus systems, this terminator helps prevent signal interference and errors, making it an essential element for reliable data communication in high-speed networks. Its precise engineering by Unitrode ensures compatibility and performance that B2B customers can rely on for mass deployments in critical applications.
UCC5606DPTR Features
The UCC5606DPTR SCSI Terminator by Unitrode offers several key features that make it a top choice for high-performance data systems. These features include nine individually terminated lines, a standard 110 ohm resistance that matches SCSI specifications, and a compact package that is easy to integrate into existing systems. Additionally, this component is designed for low-power consumption and offers high durability, providing a reliable solution for system designers and network engineers.
UCC5606DPTR Applications
- Server Backplanes: Utilized in server backplanes to ensure data integrity by minimizing signal reflection and crosstalk between multiple SCSI devices.
- RAID Systems: Essential in RAID configurations to maintain the quality of signal transmission across multiple hard drives, enhancing overall system reliability and performance.
- Data Centers: Deployed in data centers to facilitate robust data communication standards and to support high-volume data transfer and scalability without degradation in signal quality.
- Networking Equipment: Used in networking gear that relies on SCSI interfaces to optimize data throughput and reduce packet loss associated with poor termination.
