2N4014

Manufacturer :

Motorola

Product Category :

Transistors - Bipolar (BJT) - Single

Collector Emitter Breakdown Voltage :

50V

Transistor Element Material :

SILICON

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

Factory Lead Time :

8 Weeks

DC Current Gain-Min (hFE) :

60

JESD-609 Code :

e0

Package / Case :

TO-18

Polarity :

NPN

RoHS Status :

RoHS Compliant

Pbfree Code :

No

Packaging :

Bulk

Lead Free :

Lead Free

Mount :

Through Hole

Terminal Form :

Wire

ECCN Code :

EAR99

Emitter Base Voltage (VEBO) :

6V

Element Configuration :

Single

Published :

2004

Collector Base Voltage (VCBO) :

80V

Frequency - Transition :

300MHz

Terminal Position :

BOTTOM

Qualification Status :

Not Qualified

Collector Emitter Voltage (VCEO) :

50V

hFE Min :

60

Collector Emitter Saturation Voltage :

520mV

Max Collector Current :

1.7μA

Power Dissipation-Max (Abs) :

0.36W

Gain Bandwidth Product :

300MHz

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Transistor Application :

SWITCHING

Turn On Time-Max (ton) :

35ns

JESD-30 Code :

O-MBCY-W3

Number of Terminations :

3

Number of Elements :

1

Terminal Finish :

Tin/Lead (Sn/Pb)

Operating Temperature (Max) :

200°C

Transition Frequency :

300MHz
