2N5683

Manufacturer :

Microchip Technology

Product Category :

Transistors - Bipolar (BJT) - Single

Radiation Hardening :

No

Number of Elements :

1

Max Operating Temperature :

200°C

Terminal Finish :

TIN LEAD

Collector Emitter Voltage (VCEO) :

60V

JESD-30 Code :

O-MBFM-P2

Min Operating Temperature :

-65°C

JESD-609 Code :

e0

Packaging :

Bulk

DC Current Gain-Min (hFE) :

15

Published :

2007

Polarity/Channel Type :

PNP

Mount :

Through Hole

RoHS Status :

Non-RoHS Compliant

Pin Count :

2

Collector Base Voltage (VCBO) :

60V

Case Connection :

COLLECTOR

Max Collector Current :

50A

Number of Terminations :

2

Configuration :

Single

Transition Frequency :

2MHz

Max Power Dissipation :

300W

Number of Pins :

3

Lifecycle Status :

IN PRODUCTION (Last Updated: 1 month ago)

Factory Lead Time :

12 Weeks

Terminal Form :

PIN/PEG

ECCN Code :

EAR99

Pbfree Code :

No

Terminal Position :

BOTTOM
