MT323024

Manufacturer :

TE Connectivity Potter & Brumfield Relays

Product Category :

Power Relays, Over 2 Amps

Must Operate Voltage :

18 VDC

Relay Type :

GENERAL PURPOSE

Coil Operate Voltage(DC) :

18 V

Packing Method :

Bulk

Body Breadth :

35.5 mm

ECCN Code :

EAR99

Mounting Feature :

SOCKET MOUNT

Contact/Output Supply Type :

AC

Body Height :

57 mm

Termination Style :

Plug In, 11 Pin (Octal)

Manufacturer :

TE Connectivity

Relay Form :

3 Form C

Switching Voltage :

400VAC - Max

Contact Current(AC)-Max :

10 A

Contact Rating (Current) :

10A

Sealing :

RT1

Turn Off Voltage (Min) :

2.4 VDC

Features :

LED Indicator, Test Button

Coil Release Voltage(DC) :

2.4 V

Reference Standard :

UL; VDE

Coil Voltage :

24VDC

Surface Mount :

No

Physical Dimension :

35.5mm x 35.5mm x 57mm

Coil Current :

50.0mA

Coil Insulation :

-

Contact Form :

3PDT (3 Form C)

Package :

Bulk

Mounting Type :

Socketable

Packaging :

Bulk

Weight :

80 g

End Contact Material :

Silver Nickel

Coil Voltage(DC)-Max :

24 V

Coil Type :

Non Latching

Contact Material :

Silver Nickel (AgNi)

Coil Resistance :

475 Ohms

Reach Compliance Code :

Compliant

Product Status :

Obsolete

Relay Function :

3PDT

Factory Lead Time :

32 Weeks

Dielectric Strength Between Open Contacts :

1500 Vrms

Contact Current(DC)-Max :

10 A

Seal Rating :

-

Operating Temperature :

-40°C ~ 60°C

Coil Current(DC)-Max :

0.05 A

Additional Feature :

WITH TEST BUTTON AND LED

Coil Power :

1.2 W

Series :

MT, SCHRACK

Must Release Voltage :

2.4 VDC

Body Length or Diameter :

35.5 mm

Turn On Voltage (Max) :

18 VDC

Input Switching Control Type :

Random

Contact Voltage(AC)-Max :

400 V

Termination Type :

Snap-On

Base Product Number :

MT32

Dielectric Strength Between Coil and Contacts :

2500 Vrms

Release Time :

10ms

Relay Action :

Momentary

Coil/Input Supply Type :

DC

Operate Time :

15ms
