MT323048
Or copy the link below:
- Mfr.Part #
- MT323048
- Manufacturer
- TE Connectivity Potter & Brumfield Relays
- Package / Case
- Dust Cover
- Datasheet
- Download
- Description
- RELAY GEN PURPOSE 3PDT 10A 48V
- Stock
- 33,068
- In Stock ：
- 33,068
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity Potter & Brumfield Relays
- Product Category :
- Power Relays, Over 2 Amps
- Coil Current :
- 24(mA)
- Operate Time :
- 15(ms)
- Coil Voltage DC :
- 48
- Turn Off Voltage (Min) :
- 4.8 VDC
- Width :
- 35.5 mm
- Coil Resistance :
- 2000(ohm)
- Contact Termination :
- Plug In
- Turn On Voltage (Max) :
- 36 VDC
- Must Release Voltage :
- 4.8 VDC
- Seal :
- Unsealed
- Contact Rating (Current) :
- 10A
- Relay Type :
- GENERAL PURPOSE
- Product Length (mm) :
- 35.5(mm)
- Release Time :
- 10ms
- Product Category :
- General Purpose Relays
- Product Depth (mm) :
- 35.6(mm)
- Termination Style :
- 11-Pin Circular Plug
- Pick-up Voltage (Max) :
- 36VDC
- Pin Count :
- 11
- Relay Construction :
- Non-Latching
- Contact Current Rating :
- 20(A)
- Coil Voltage :
- 48VDC
- Maximum Power Rating :
- 2.5KVA
- Subcategory :
- Relays
- Type :
- Multimode
- Height :
- 57 mm
- Brand :
- TE Connectivity / AMP
- Product Type :
- General Purpose Relays
- Product Height (mm) :
- 57(mm)
- Contact Arrangement :
- 3PDT
- LED Indicator :
- yes
- Manufacturer :
- TE Connectivity
- Mounting Style :
- Plug-In
- Coil Insulation :
- -
- Base Product Number :
- MT32
- Operating Temperature :
- -40°C ~ 60°C
- Operating Temp Range :
- -40C to 60C
- Dropout Volt :
- 4.8VDC
- Rad Hardened :
- No
- Coil Type :
- Non Latching
- Product :
- Power Relays
- Power Consumption :
- 1.2 W
- Contact Form :
- 3 Form C
- Coil Suppression Diode :
- No
- Voltage Rating (VAC) :
- 400(V)
- Must Operate Voltage :
- 36 VDC
- Features :
- LED Indicator, Test Button
- Coil Power :
- 1.2 W
- Series :
- MT, SCHRACK
- Switching Voltage :
- 400VAC - Max
- Packaging :
- Box or Tray
- Package / Case :
- Dust Cover
- Package :
- Bulk
- Contact Material :
- Silver Nickel 90/10
- Seal Rating :
- -
- Length :
- 35.5 mm
- Mounting Type :
- Socketable
- Product Status :
- Obsolete
- Datasheets
- MT323048
