REXL2TMF7

Manufacturer :

Schneider Electric

Product Category :

Time Delay Relays

Type of electric connection :

Plug-in connection

Contact Configuration :

DPDT

Nominal current :

5

Mounting Type :

Socketable

Rated control supply voltage at AC 50 Hz :

120 - 120

RoHS :

Details

Contact Current :

5A

Height :

27

Subcategory :

Timers

Series :

Harmony

Maximum Operating Temperature :

+60°C

Contact Rating @ Voltage :

-

Product Category :

Timers

Relay Type :

Mechanical Relay

Rated control supply voltage at DC :

0 - 0

Time Delay :

0.1 → 1 h, 0.1 → 1 s, 0.1 → 10 min, 1 → 10 h, 1 → 10 min, 1 → 10 s, 10 → 100h

Mode of Operation :

Electromechanical

Package :

Box

Rated control supply voltage at AC 60 Hz :

120 - 120

Voltage type for actuating :

AC

Timing Adjustment Method :

Hand Dial

Number of Contacts :

2

Brand :

Schneider Electric

Delay Time :

0.1 Sec ~ 100 Hrs

Function :

On-Delay

Timing Initiate Method :

Input Voltage

Depth :

63

Manufacturer :

Schneider Electric

Contact Material :

Silver Nickel

Product Status :

Active

Product Type :

Timers

Width :

21

Switch Configuration :

DPDT

Supply Voltage :

110V AC

Minimum Operating Temperature :

-20°C

Voltage - Supply :

120VAC

Circuit :

DPDT (2 Form C)

Termination Style :

Plug In
