REXL4TMB7

Manufacturer :

Schneider Electric

Product Category :

Time Delay Relays

Width :

27mm

Product Type :

Timers

Brand :

Schneider Electric

Package :

Box

Manufacturer :

Schneider Electric

Subcategory :

Timers

Relay Type :

Mechanical Relay

Voltage - Supply :

24VAC

Series :

Harmony

Termination Style :

Plug In

Product Category :

Timers

Length :

59.5mm

Mounting Type :

Socketable

Time Delay :

0.1 → 1 h, 0.1 → 1 s, 0.1 → 10 min, 1 → 10 h, 1 → 10 min, 1 → 10 s, 10 → 100h

Timing Initiate Method :

Input Voltage

Contact Rating @ Voltage :

-

Number of Contacts :

4

Mode of Operation :

Electromechanical

Product Status :

Active

Depth :

21mm

Maximum Operating Temperature :

+60°C

Contact Material :

Silver Nickel

Circuit :

4PDT (4 Form C)

Minimum Operating Temperature :

-20°C

Switch Configuration :

4PDT

RoHS :

Details

Delay Time :

0.1 Sec ~ 100 Hrs

Timing Adjustment Method :

Hand Dial

Supply Voltage :

24V ac

Function :

On-Delay
