738-124

Manufacturer :

WAGO

Product Category :

Wire to Board

Pollution degree :

2

Voltage :

300 V

Connection :

Spring-loaded terminal,Print

Package :

Box

Cross section (flexible) (max.) :

2.50mm²

Connectable conductor cross section solid-core :

0.08 - 2.5

Number of Poles :

24

Rated current In :

18

Automotive :

No

Type of fastening :

Solder

Height :

48.20mm

Mounting Type :

PCB Mount

Cross section (flexible) (min.) :

0.08mm²

ECCN (US) :

EAR99

Pins per row :

24

Connectable conductor cross section fine-strand with cable end sleeve :

0.25 - 1.5

Product Status :

Active

Rated surge voltage :

4

Min. stripping length :

18mm

Composition :

Polyamide

Connectable conductor cross section fine-strand without cable end sleeve :

0.08 - 2.5

Nominal voltage :

320V

Cross section (inflexible) (max.) :

2.50mm²

Flammability Rating :

UL94 V-0

Packaging type :

Other

CS :

5mm

Color :

Gray

RoHS :

yes

Length :

37.50mm

HTS :

8536.90.40.00

Number of Levels :

4

EU RoHS :

Compliant

Wire protection :

yes

Number of Rows :

1

Approvals :

cURus;CSA

Cross section (inflexible) (min.) :

0.08mm²

Torque - Screw :

-

Connectable conductor cross section multi-wired :

0.08 - 2.5

Inflammability class of insulation material according to with UL94 :

V0

Wire Gauge :

12-28 AWG

AWG (min.) :

28

Contact Material :

Copper, Tin

Screw Material - Plating :

-

Operating Temperature :

-60°C ~ 105°C

Manufacturer part # :

738-124

AWG max. :

12

Series :

738

Stripping length (max.) :

6mm

No. of rows :

1

Positions Per Level :

24

Housing Color :

Grey

Housing Material :

Polyamide (PA66), Nylon 6/6

Features :

+ CAGE CLAMP®

PPAP :

No

Mating Orientation :

45° (135°) Angle with Board

Number of Pins :

96

Wire Termination :

Screwless - Spring Cage, Tension Clamp

Type :

738-124

Current :

10 A

Content :

6pc(s)

Screw Thread :

-

Clamp Material - Plating :

Steel - Nickel Plated

Over voltage category :

III

Width :

121.00mm

Connection Type :

Spring Clamp

Pitch :

0.197 (5.00mm)

Pin Length :

4 MilliMeters

Industrial packaging :

yes

Contact Material - Plating :

Electrolytic Copper - Tin Plated

Manufacturer :

Wago

Temperature Range :

-76 to 221 Degrees F
