738-202

Manufacturer :

WAGO

Product Category :

Wire to Board

Connection Type :

Spring Clamp

Approvals :

CSA, cURus

Package :

Box

Operating Temperature :

-60°C ~ 105°C

Temperature Range :

-76-221 °F

Wire protection :

yes

Cross section (inflexible) (max.) :

2.50mm²

Nominal voltage :

320V

Torque - Screw :

-

AWG max. :

12

Pitch :

0.197 (5.00mm)

Wire Termination :

Screwless - Spring Cage, Tension Clamp

Screw Material - Plating :

-

Type :

738-202

Stripping length (max.) :

6mm

Features :

+ CAGE CLAMP®

Cross section (flexible) (max.) :

2.50mm²

Cross section (flexible) (min.) :

0.08mm²

Mounting Type :

PCB Mount

Content :

72pc(s)

Height :

37.50mm

Industrial packaging :

yes

Pins per row :

2

Cross section (inflexible) (min.) :

0.08mm²

Contact Material - Plating :

Electrolytic Copper - Tin Plated

Manufacturer :

Wago

Color :

Gray

Manufacturer part # :

738-202

Current :

10 A

Voltage :

300 V

Number of Levels :

4

No. of rows :

1

Mating Orientation :

45° (135°) Angle with Board

Width :

48.20mm

Product Status :

Active

AWG (min.) :

28

Screw Thread :

-

Wire Gauge :

12-28 AWG

Housing Material :

Polyamide (PA66), Nylon 6/6

Positions Per Level :

8

Length :

11.00mm

Number of Poles :

2

Min. stripping length :

18mm

Clamp Material - Plating :

Steel - Nickel Plated

RoHS :

yes

CS :

5mm

Composition :

Polyamide

Connection :

Spring-loaded terminal,Print

Series :

738

Pin Length :

4 mm
